The table 1. The multichannel technological registrars RMT with input signals from thermal
converter of resistance and thermoelectric converters
Input parameters
On НСХ
Type of the
primary
converter
W
100
Range of
measured
temperatures, С
Resistance, Оhm
Thermo-
emf., мV
input
resistance ,
KOhm
limits of the basic
indicated
admissible error,
%
1 2 3 4 5 6 7
50М
39,23÷92,78
100М
1,4280
78,45÷185,55
50М
39,35÷92,62
100М
1,4260
-50÷200
78,69÷185,23
50П 1,3910
29,82÷141,95
100П
59,64÷283,89
Pt100 1,3850
-100÷500
60,26÷280,98
-
-
±(0,25+*)
ТХА
ХА(К)
0÷1300 0÷52,398
ТХК
ХК(L)
0÷600 0÷49,098
ТПП
ПП(S)
-
0÷1300
-
0÷13,155
not less than
30
±(0,5+*)
The table 2. Multichannel technological registrars RMT with input electrical signals in form
of the direct current voltage or of the direct current
source parameters
Measured
quantity
measuremen
ts range
Resistance, МOhm, -
not less
voltage, мV, no more
Limits of the basic
Indicated admissible error,
%
0÷5**
0÷20
4÷20**
105
0÷5
Current, мА
4÷20
-
100
0÷75
voltage, мV
0÷100
0,1
-
±(0,2 + *)
* - one unit of the last category expressed in percentage of measurements range ;
** - for RMT with unified source signals the dependence of the measured quantity from the
input signal can be either linear, or with a square root extraction function.
3.12. The RMT indications variation is within the limits of +- 0,2 %.
