3. SPECIFICATIONS AND CHARACTERISTICS
3.1. Number of measuring channels -
3.2. Number of recording channels -
3.3. Parameters of the device configuration:
Parameter parameter
designation
factory
installation
Channel 1 channel 2 channel 3
The network address Un 1
Speed of exchange SPd 9,6
Time of indication (seconds) tind 3
Allowed inst. Progr EnP 1
The configuration password PScF 0000
Type of the gauge dAt t420
The switching diagram Lc c3
Marks after the point UF 1
Averaging nS 1
min of the indication range dP1 0
max of the indication range dP2 100
Square root Sqr 0
Zone of return GSt 0,5
Resolution of relay working EnU 1
Relay 1 at the gauge breakage rL1 0
Relay 2 at the gauge breakage rL2 0
Relay 3 at the gauge breakage rL3 0
Relay 4 at the gauge breakage rL4 0
min of the record range PP1 0
max of the record range PP2 100
Compensator calibration R0 Clr ---
Line calibration R Clc ---
Replacement of recording devices Pen --- --- ---
3.4. The ranges of measurements, source parameters and limits of the admitted indicated basic
errors of RMT measured quantities taking into consideration their configurations conform to those
ones indicated in the table 1 and table 2.
The basic indicated error on the computer channel RMT does not exceed the basic indicated
error on the measuring channel.
3.5. Limit of the basic indicated error on record of measured quantity is ±1 %.
3.6. Limit of the basic relative error on time record is
0,05 %
3.7. The RMT tolerance zone of is in limits of
0,2 %.
3.8. The maximum significance of friction effect expressed in percentage of graduation length
(width of a record field), does not exceed 0,3 %.
3.9. Reproducibility of the measurements results is not more than 0,2 %.
3.10. The instability of RMT indications during 10 days (long drift) is not more than
0,4 %.
3.11. The working mode establishment time is not more than 20 minutes.
