-2-
Important: If any parts are missing or damaged, DO NOT RETURN TO RETAILER. Call toll-free (800) 533-2441 or e-mail us at:
help@elenco.com. Customer Service • 150 Carpenter Ave. • Wheeling, IL 60090 U.S.A.
Parts List (Colors and styles may vary) Symbols and Numbers
Qty. ID Name Symbol Part # Qty. ID Name Symbol Part #
r 1
Base Grid
(11.0” x 7.7”)
6SCBG
r 1
Fan Blade 6SCM1F
r 6
1-Snap Wire 6SC01
r 2
NPN Transistor 6SCQ2
r 9
2-Snap Wire 6SC02
r 1
100W Resistor 6SCR1
r 4
3-Snap Wire 6SC03
r 2
1kW Resistor 6SCR2
r 3
4-Snap Wire 6SC04
r 2
10kW Resistor 6SCR4
r 1
5-Snap Wire 6SC05
r 1
100kW Resistor 6SCR5
r 1
6-Snap Wire 6SC06
r 1
Photoresistor 6SCRP
r 1
7-Snap Wire 6SC07
r 1
Adjustable Resistor 6SCRV
r 1
Battery Holder - uses
3 1.5V type AA (not
Included)
6SCB3
r 1
Slide Switch 6SCS1
r 1
470mF Capacitor 6SCC5
r 1
Press Switch 6SCS2
r 1
Red Light Emitting
Diode (LED)
6SCD1
r 1
8 Ohm Speaker 6SCSP
r 1
Green Light Emitting
Diode (LED)
6SCD2
r 1
Microcontroller IC 6SCU21
r 1
Jumper Wire (Black) 6SCJ1
r 1
Microphone 6SCX1
r 1
Jumper Wire (Red) 6SCJ2
r 1
Programming Cable 9TLSCXP
r 1
DC Motor 6SCM1
You may order additional / replacement parts at our website: www.snapcircuits.net
5
4
3
2
1
RP
U21
S2
R2
X1
B3
D1
C5
D2
R1
SP
6
7
M1
Q2
R5
R4
RV
S1
