AIR INLET
(FOR COOLING FAN)
SCALE
REF.DRG.No.
NAME DATE
CAD
CHECKED
MODEL.
MATERIAL
DATEECO.No.REV. NO. DESCRIPTION
R
CHKD. BY
ALT. BY
REMARKS
Rev.DESCRIPTION
A
B
ELGI EQUIPMENTS LTD.,
COIMBATORE - INDIA.
REVISIONDRG.SHEET
DRG.No.
NEXT ASSY.
Sl.No.
APPROVED
Qty.
DRAWING No.
-
EG 11,15,18,22 (USA & BRAZIL)
SS
NTS
0 1
5 3 1 5 5 7
8
0
1
1 2
:
- CRITICAL CHARACTERISTIC (SAFETY/REGULATORY)
- SIGNIFICANT CHARACTERISTIC (FIT/FORM/FUNCTION/FINISH)
:
WEIGHT
31.01.17
SS
PMD
31.01.17
31.01.17
9
15
(30"±0.2")
27"
28"±0.4"
X
Y
(8") (27")
(8")
58"±0.4"
51"±0.4"
4"
56''±0.4"
(7")
(7") (7")
Z
12
7
3
8
MAIN POWER
CABLE ENTRY
Ø1.97"
EARTHING
POINT
DISCHARGE
AIR OUT
14
4
5
17
6
2
11
10
1
G
1
4
" MOISTURE
DRAIN
CENTRE OF GRAVITY
X Y Z
27.95"
23.62" 11.81"
1 MOTOR 1
2 AIR END 1
3
AIR - OIL SEPARATOR TANK
1
4 OIL FILTER 1
5 AIR FILTER 1
6 INTAKE VALVE 1
7
MINIMUM PRESSURE VALVE
1
8 COOLER FAN
19
CONTROL PANEL
2*
10
OIL AND AFTER COOLER ASSY
1
11 DRIVE COUPLING 1
12
AIR OIL SEPERATOR
1
13
MOISTURE SEPERATOR WITH ADV
1
14
PRE FILTER
1
15
VARIABLE FREQUIENCY DRIVE (VFD)
1
16
CONTROLLER
1
S.NO
DESCRIPTION QTY
NOTE :
1. Indicates Ducting Dimension
2. All dimensions without tolerance are for reference only
3. Cooling air flow for duct is 247202 ft³/hr.
Pressure drop in conduit should not be more than 0.00435 psi g
4. Minimum distance required around the compressor is 3.3ft
at all sides and 6.6ft at top (Installation requirement)
5. VFD available in CV version only
6. For EG 11 model fan qty 1 no mounted on Fan 2 position
7. For EG 15 to EG 22 models cooling fan qty 2 no's
8. 'a' mentioned place for fork lift access
9. 'b' mentioned place for pallet truck access
HOT AIR OUTLET (FROM COOLING FAN)
AIR INLET FOR MOTOR COOLING
13
17 1
SAFETY VALVE
1" NPT MALE AIR
OUTLET PIPE
FAN1
FAN 2
GA DRAWING-EG SERIES
C AND CV
16
COMPRESSOR
SUCTION
AIR IN
MODEL C CV
EG 11
EG 15
EG 18
EG 22
1301
1344.8
1499
1410
1521
1565
1576
1521
UNIT WEIGHT DETAILS (lbs)
b
b
a
a
VFD DISPLAY
PANEL
1
3"±0.2"
10"
3"
17"typ
24"typ
45"typ
5.6"
31"
15"
2.8"
1.6"
7"
7"
12"
1.14"
Ø0.59" -4No's
M6x4 For ducting
OIL POUR
OIL SIGHT
GLASS
OIL DRAIN
SIZE G1/2"
VENTILATION
FOR PANEL
OIL DRAIN
(3.6")
