ELGi TS05 - User Manual

Questions and Answers

W
William LindseyAug 7, 2025
Why is my ELGi Air Compressor overheating?
- T
  Thomas BrownAug 7, 2025
  Your ELGi Air Compressor may be overheating due to several reasons: the oil may be dirty, requiring an oil change; the oil level might be low, needing you to fill it to the maximum level with the correct grade of oil; the cylinder and cooler fins could be dirty, requiring cleaning with compressed air or manually; the breather valve may not be working; or the rotation might not be correct, requiring you to interchange two of the incoming power feeds to the motor.
C
craig57Aug 12, 2025
What to do if there is oil carry over in compressed air from my ELGi Air Compressor?
- S
  Scott JohnsonAug 13, 2025
  If you notice oil carry over in the compressed air from your ELGi Air Compressor, it could be due to a dirty air filter, which requires replacement. Alternatively, the oil level might be too high, needing adjustment to the correct level. It could also be that the oil viscosity is too low, requiring a change to the recommended grade. Other potential causes include a non-functioning breather, stuck or broken piston rings (change rings as a set), or excessive clearance between the piston and cylinder, which needs checking and changing as required.
M
Maureen ChavezAug 17, 2025
What causes cylinder, piston and ring wear in ELGi Air Compressors?
- M
  Melinda ClarkAug 17, 2025
  Cylinder, piston, and ring wear in ELGi Air Compressors can be attributed to inadequate filter maintenance, suggesting an increase in the frequency of cleaning or changing the filter. It may also be caused by insufficient oil change frequency, indicating a need to increase the frequency with more periodic checks of the oil. Another possible cause is using an incorrect grade of oil, which requires changing to the correct grade.
J
John WoodAug 22, 2025
What to do if my ELGi TS05 does not unload?
- M
  Mark MartinAug 22, 2025
  If your ELGi Air Compressor isn't unloading, the unloader tubing might be blocked, so you should open and clean it. Alternatively, the unloader itself may be defective, so you should replace the pressure switch.
A
Anthony HobbsAug 27, 2025
Why is there oil leaking through the breather valve of my ELGi Air Compressor?
- N
  Nicole DeanAug 27, 2025
  Oil leaking through the breather valve of your ELGi Air Compressor can occur if the piston rings are stuck or broken, requiring you to change the rings as a set. It could also be due to a breather valve that is not working, which means you should check all related parts for wear. Another possibility is excessive clearance between the piston and cylinder, so check and change as required.
M
Miss Diana MerrittSep 1, 2025
Why is there water or rust formation in the crankcase of my ELGi Air Compressor?
- J
  Jennifer EscobarSep 1, 2025
  Water or rust formation in the crankcase of your ELGi Air Compressor may be due to a faulty breather valve. Check and replace the breather.

Summary

Safety Precautions

Installation Procedures

Inspection Upon Receiving

Handling Guidelines

Location Requirements

Requirements for selecting an appropriate indoor installation site.

Space Requirements

Recommended clearances for ventilation and maintenance access.

Electrical Wiring

Instructions and warnings for electrical wiring procedures.

Control Panel

Wiring Schematics

Diagrams illustrating single and three-phase compressor wiring.

Maintenance Schedule

Daily Maintenance

150 Hour;10 Day Maintenance

250 Hour;20 Day Maintenance

500 Hour;1 Month Maintenance

1000 Hour;3 Month Maintenance

2500 Hour;1 Year Maintenance

Pressure Switch Adjustment

Guide to adjusting the compressor's pressure switch settings.

Troubleshooting Guide

Compressor Overheating Issues

Common causes and solutions for compressor overheating.

Compressor Not Unloading

Troubleshooting steps for when the compressor fails to unload.

Oil Carry Over

Causes and solutions for oil in the compressed air.

Cylinder, Piston, Ring Wear

Diagnosing and addressing wear on internal components.

Crankcase Water;Rust

Identifying and resolving water/rust issues in the crankcase.

Oil Leak Through Breather Valve

Troubleshooting oil leaks from the breather valve.

Compressor Knocking

Solutions for knocking sounds from the compressor.

Excessive Pressure Build-up Time

Leaky Unloader Valve

Pressure Switch Malfunction

Diagnosing problems with the pressure switch.

Compressor Package Vibration

Starter Chattering

Contactor Tip Welding

Starter Tripping

Solutions for general starter tripping issues.

Motor Not Running Correctly

Troubleshooting steps when the motor fails to operate correctly.

Motor Faulty Diagnosis

Diagnosing and resolving motor faults.

ELGi TS05 Specifications

General

Power	5 HP
Tank Capacity	200 liters
Max Pressure	175 PSI
Number of Stages	2
Number of Cylinders	2
Drive Type	Belt Drive
Cooling System	Air Cooled
Lubrication Type	Oil Lubricated
Type	Reciprocating
