24
TS Series
8.1 Replacement Pump Parts - TS 7.5
Fig # Description Qty Part No.
01 Compressor 7.5 HP 1 01-01-502
02 Pulley
1 A 02 0056
03 Cooling fan
04 Washer, spring rectangular, M8
05 Bolt, hex, M8 x 20
