TS Series
8.1 Replacement Pump Parts - TS07
Fig
#
Description Qty Part No.
1 Crank case 1 00 02 1278 0
2 Stud M12 x 45 8 00 05 1456 A
3 Gasket, Free end cover 1 00 04 2546 0
4 Free end cover 1 00 03 6546 0
5 Spring washer M8 12 00 09 96 108
6 Bolt Hex. M8x25 12 00 09 06 116
7 Pipe, breather 1 02 04 9285 0
8 Reducer ½” BSP x 1” BSP 1 02 04 9246 0
9 Breather assembly 1 A02 0030
10 Rink packing, 17x22x2 1 00 05 2186 0
11 Oil Drain plug, 3/8” BSP 1 A02 0033
12 ‘O’ Ring, OLI 1 00 05 2655 0
13 Oil Level Indicator 1 00 05 1344 0
14
Conn. rod & Combined Crank
shaft assy.
1 02 03 6253 0
14a
Conn. rod & Combined Crank
shaft assy.
1 A02 0433
15 Bearing 6307 1 00 09 03 352
16 Bearing 6309 1 00 09 03 358
17 Gasket, Fly end cover 1 00 04 5463 0
18 Oil seal, B45x60x12.5 1 00 04 2035 0
19 Fly end cover 1 02 03 5463 0
20 Piston, dia 100 1 00 32 6183 0
21 Circlip, B 20 2 00 09 17 220
22 Gudgeon pin, Dia 20 1 00 05 1419 0
23
Ring, slotted oil control, Dia
100
2 00 04 1686 0
24
Ring, stepped compression,
Dia 100
1 00 04 1757 0
25
Ring, Taper plain compres-
sion, Dia 100
1 00 04 1685 0
26
Gasket, C/Case to Cylinder,
0.25
1 00 04 1004 A
Gasket, C/Case to Cylinder,
1.00 mm
1 00 04 1004 D
Fig
#
Description Qty Part No.
27 Cylinder, dia 100 1 02 02 1010 0
28 Spring washer M12 8 00 09 96 112
29 Nut, Hex. M12 8 00 09 48 012
30
Stud, M12 x 86 3 00 04 7004 0
Stud, M12 x 96 1 00 05 1450 0
31 Valve finger 4 00 03 3097 0
32 Gasket, Cyl. To Valve flat 1 00 04 1156 A
33 Valve Flat 1 00 03 1007 0
34 Gasket, Valve flat to Head 1 00 04 6210 A
35 Centring Bush 4 00 04 2660 0
36 Head, dia 100 Cyl. 1 00 02 1238 0
37 Spring washer M12 8 00 09 96 112
38 Nut, Hex. M12 8 00 09 48 012
39 Nipple, Pipe 1 ¼” BSP 1 00 04 3217A
40 Piston dia 60 1 00 02 1210 0
41 Circlip B 18 2 00 09 17 218
42 Gudgeon pin, Dia 18 1 00 05 1415 0
43
Ring, slotted oil control,
Dia 60
2 00 04 1688 0
44
Ring, stepped compres-
sion, Dia 60
1 00 04 2033 0
45
Ring, Taper plain com-
pression, Dia 60
1 00 04 1687 0
46 Cylinder, dia 60 1 00 02 1011 0
47
Stud, M12 x 60 3 00 05 2013 0
Stud, M12 x 70 1 00 05 1883 0
48 Valve finger 2 00 03 3095 0
49 Gasket, Cyl. To Valve flat 1 00 04 1152 A
50 Valve Flat 1 00 03 1008 0
51 Gasket, Valve flat to Head 1 00 04 1153 A
52 Head, dia 60 Cyl. 1 00 02 1112 0
53 Connecting Piece 1 02 04 9609 0
54 Ring, Packing 2 00 05 2191 0
55 Inter cooler 1 00 03 1009 0
56 Safety valve assembly, 1 A02 0001
57 Name plate, RAC Unit 1 02 03 5180 R
