EL2305D Access Control Panel
NOTE: if you have chosen any of the points to be “GP” instead of “EVENT”,
then this command will have no effect on those points.
2.5.1 OUTPUT DURATION COMMAND (Out Dur)
This setting is to set the duration for which the output point is to stay activated
when it is set to the “PULSE” mode.
The value from 0 until 999 seconds, individually for each of the 6 outputs.
2.6.1 BAUD RATE (Baud Rate)
You can choose the baud rate to any of the following 2400, 4800, LAN, 19200,
38400 and COM2.
The factory setting will be 9600 baud rate.
Output Duration
1 005 SEC
To Next Page
