EL2305D Access Control Panel
2.7.3 TEST INPUT (Test IN)
The display indicates the status of the Door Switch (DS), Push Button (PB),
Sensor #1 (S1), and Sensor #2 (S2)
0=Contact Open, and 1= Contact Closed.
2.7.4 TEST OUTPUT (Test OUT)
On entering this command, the following display will show:-
If Key 1 is pressed, the Duress Alarm Output for both EA8 is switched on and
the display will show: -
