EL2305D Access Control Panel
2.7.5 TEST COMMUNICATION (Test Com)
Echo Test: Used PC linked via EL70 to controller. Run a communication
program such as HyperTerminal on the PC and set it to behave as a terminal.
Printer Test: the controller will send a stream of characters out of the serial
port.
2.7.6 TEST 7 SEGMENT (Test 7sg)
As you press any of the keys on the door 1 serial keypad, the value of the key
will be displayed on the 7-segment display.
7-Segment Test
Dr 1, * to quit
