EL2305D Access Control Panel
User Guide
Revision 1.1.20
7
1.5 SETTING DISPLAY TYPE
Press <D> key to select “DISPLAY TYPE” command.
Code
Details
WIEG
Wiegand Reader, with 26-bit Wiegand format
PROX
Proximity Reader, with ELID format
EPRX
Diester Reader, with 48 bit Diester format
FWIE
Free Wiegand Reader, with 32bit format
PIN
MatrixPIN Keypad Reader only
EL2305D SET-UP
Disp Type ER5S
