Elite Screens Elite ezFrame Series User Manual

Parts List
1. Frame Parts x 6 pcs (4 top/bottom frame pcs. + 2 side frame pcs)
2. Tension Rods x 6 pcs (4 top/bottom rods + 2 side rods)
3. Screen Material x 1 pc
4. Center joints x 2 pcs
5. Elbow Joints x 4 pcs
6. Wall brackets x 2 – 3 pcs (depending on model/size)
7. Screws x 16 pcs
8. User Guide x 1 pc
9. Center Support Bar x 1 – 2 pc s (depending on model/size)
10. Support joiner x 2 – 4 pcs (depending on model/size)
11. Fix Plates x 30 – 90 pcs (depending on model/size)
12. Black cloth backing x 1 pc (AcousticPro1080 models only)
Note: Please make sure all parts are included in your package before proceeding to assemble
your Elite Screens fixed frame projection screen.
ASSEMBLING THE FRAME
1. Insert the center joint connector to the horizontal frame piece and then fasten it with 2 screws
2. Insert the other horizontal frame piece to the center joint connector and then fasten it with 2 screws.
(1)
1/2Long frame
Push
