Elite Screens Starling Tab-Tension 2 Series Replacement Instructions

Updated 04/04/2017 2 www.elitescreens.com
3. Once the washer is removed, you can now remove the back plate of the cap.
4. Once the back plate is removed, you can unwind the string as shown in the picture on the right.
5. After unwinding the string, you can pull out the knob. Be aware that the face plate will fall off.
6. A Lastly, untie the knot that tightens the string to the knob. This will then allow for you to pull out
the broken weight bar cap.
7. To install the new cap, simply follow these instructions in reverse order.
For a local Elite Screens contact or Technical Support, please visit
www.elitescreens.com
Black plate removed
Knob
Tension string

Elite Screens Starling Tab-Tension 2 Series Specifications

General

Format	HDTV
Diagonal	100 \
Drive type	Motorized
Screen gain	1.1
Native aspect ratio	16:9
Viewable screen width (W)	2214.9 mm
Viewable screen height (H)	1244.6 mm
Overall screen size (Height x Width)	190.75 x 239.01 cm
Case color	Black
Mounting type	Ceiling/wall
Product color	White

Weight and Dimensions

Height	2067.6 mm
Case L1	2639.1 mm
