Elived EV014 - Page 9

- 9 -
STEP 4 Adjustments
(Leveling)
Loosen
Tighten
±3°
Leveling adjustment (-3°/+3°)
If needed, TV can be leveled ±3 degrees via adjusting the 2 screws with the open-end
wrench.
(Tool-free Tilting Adjustment)
-12°
+5°
If necessary
C
Tighten
Loosen
If TV keeps tilting down, Pull TV to desired
angle then fasten tilting nuts with open-
end wrench.
C
± 3°
