This document outlines the installation and features of the ELIVED EV014 TV wall mount.

Function Description

The ELIVED EV014 is a full-motion TV wall mount designed to securely hold flat-screen televisions. It allows for various adjustments including tilting and leveling, providing an optimal viewing experience. The mount is compatible with both solid concrete/brick walls and wood stud drywall installations, offering flexibility for different home environments. The installation process is detailed with step-by-step instructions and illustrations, ensuring a safe and proper setup.

Important Technical Specifications

TV Compatibility:

Screen Size: 42" to 70"
VESA Compatibility:
- Minimum: 150x100mm (6x4")
- Maximum: 600x400mm (24x16")
Weight Capacity: Maximum 45.5 KG (100 LBS)

Wall Compatibility:

Solid concrete wall
Drywall with wood studs
Caution: Not suitable for installation into drywall alone. The wall must be capable of supporting five times the weight of the TV and mount combined.

Adjustments:

Tilting: +5° to -12° (tool-free adjustment)
Leveling: ±3°

Dimensions (Product):

Wall Plate Width: 433mm
Wall Plate Height: 187mm
Max Extension from Wall: 690mm
Min Distance to Wall: 72mm
Overall Mount Height (with brackets): 422mm
Overall Mount Width (with brackets): 408mm

Hardware Included:

Wall Plate (x1)
Front Support (x1)
Arm Extensions (x2)
Brackets (x2)
Wrench (x1)
Lag Bolts (5/16 x 2½ in / ST8 x 65mm) (x6)
Washers Ø8mm (x6)
Open-end wrench (x1)
Concrete Wall Anchors (x6) (Not for drywall or wood stud installation)
Various TV screws (Philips M4x12mm, M4x30mm, M6x15mm, M6x30mm, M8x25mm, M8x45mm)
Spacers (L10mm, L5mm)
Washers Ø6mm (M4-5-6)
Bubble level (x1)
Mounting template (x1)

Tools (Not Included):

Band Tape (2m)
Pencil
Screwdriver
Electrodrill
Socket Wrench (1/2" / 13mm)
For Concrete Install: 3/8" (10mm) Masonry Drill Bit, Hammer
For Wood Stud Install: Stud Finder, Awl, 7/32" (5.5mm) Wood Drill Bit

Usage Features

Easy Installation: The manual provides clear, illustrated instructions for each step of the installation process, from selecting the correct TV screws to mounting the wall plate and hanging the TV. A bubble level and mounting template are included to assist with accurate positioning and leveling.

Versatile Wall Mounting: The EV014 supports installation on both solid concrete/brick walls and drywall with wood studs. Specific instructions and hardware are provided for each wall type, ensuring a secure fit. For wood stud installation, a stud finder is recommended to locate the center of the studs.

Tool-Free Tilting Adjustment: The mount features a convenient tool-free tilting mechanism, allowing users to easily adjust the TV's vertical angle from +5° to -12° to reduce glare and achieve the best viewing angle. Once the desired tilt is set, the tilting nuts can be tightened with an open-end wrench for security.

Leveling Adjustment: After installation, the TV's horizontal level can be fine-tuned by ±3°. This adjustment is made by loosening and tightening two leveling bolts on the back of the TV plate with an open-end wrench, ensuring the TV is perfectly straight.

Full Motion Capability: While not explicitly detailed in the provided pages, the "Arm Extensions" and "Front Support" components, along with the "Tool-free Tilting Adjustment," suggest that this is a full-motion mount, allowing the TV to be pulled away from the wall and swiveled horizontally in addition to tilting. The "Max Extension from Wall: 690mm" further supports this, indicating a significant range of motion.

Safety Precautions: The manual emphasizes reading all instructions carefully and contacting customer service if there are any doubts about safety or installation. It warns against installing the product into drywall alone and stresses that the wall must support five times the combined weight of the TV and mount.

Maintenance Features

The document does not explicitly detail maintenance features. However, the design of the mount, particularly the adjustable components for tilting and leveling, implies that these mechanisms can be re-adjusted over time if needed. The use of durable materials and robust hardware ensures long-term stability. Regular checks to ensure all screws and bolts remain securely fastened would be a recommended general maintenance practice for any wall-mounted TV. The instructions for tightening tilting nuts and leveling bolts suggest that these are points of adjustment that users can manage to maintain optimal TV positioning.
