Elived YD1003 - Step 4 A-4: Secure Wall Plate (Wood stud); Step 4 B: Wall Plate Installation (Concrete or Brick); Position and Mark Hole Locations; Drill Pilot Holes for Concrete

4A-4
01
A
Install wall plate using lag bolts
and washers B . Tighten the lag bolts
until they are pulled firmly against the wall
plate .
01
- 8 -
01
Position the wall plate at
your desired height , level
the wall plate and mark the
polit hole locations.
Drill pilot
holes
4B-2
4B-1
2.75in 70 mm
Ø 10 mm
Ø 10 mm
STEP 4B Wall Plate Installation (Concrete or Brick)
AB
01
01
A
B
UP
