Elived YD1008 - Product Dimensions

Product dimensions:
- 10 -
Switch Screen Horizontally and Vertically
+3°/-10°
380mm
68mm
210mm
200mm
100mm
115.8mm
If needed, the TV can be rotated ±90 degrees for switching screen between horizontally and vertically.
Use the open end wrench to loosen and tighten
this screw if necessary.
Screwdriver can be used for adjusting the screw
to secure the TV direction if need.
Horizontal screen
±90°
Vertical screen
B
0° up
90° up
