Elived YD1008 - STEP 3-3 Attach the Brackets

STEP 4A Wall Plate Installation (Wood stud)
4A-1
Locate your studs. Verify and
mark the center of the stud by
finding the stud edges using an
awl, a thin nail, or an
edge-to-edge stud finder.
- 6 -
M-B
M-A
Use the shorter
screws
M-B
M-C
M-E
Not for M8 screws
M-B
M-A
Use the longer screws
M-B
M-E
Not for M8 screws
M-FM-D
STEP 3-3
Attach the Brackets
(a) for Flat Back
(b) for Round Back / Extra space
Top of TV
Top of TV
