4A-2
Position the wall plate at
your desired height and line up
the holes with your stud center
line. Level the wall plate and
mark the pilot hole locations x2.
01
4A-3
Drill pilot holes using a 5/32 in. (4 mm)
diameter drill bit.
IMPORTANT:
Pilot holes must be
in. (70 mm).
Be sure to drill into the center of the stud.
drilled to a depth of
5/32 in.
Ø4 mm
in. (70 mm)
4A-4
01
A
A
Install wall plate using lag bolts .
Tighten the lag bolts until they are
pulled firmly against the wall plate .
01
- 7 -
01
Level
01
A
UP
