Position the wall plate at
your desired height , level
the wall plate and mark the
pilot hole locations x2.
4B-1
A
STEP 4B Wall Plate Installation (Concrete or Brick)
Contact us by email help@elivedglobal.com to have
these additional pieces shipped directly to you.
Concrete Wall Anchor
3pcs
Concrete wall anchor (NOT INCLUDED)
01
A
A
01
Install wall plate using
lag bolts and anchors (not
included). Tighten the lag
bolts until they are
pulled firmly against the wall
plate .
01
Level
4B-2
4B-3
2.75in 70 mm
Ø 10 mm
Ø 10 mm
Drill pilot holes
01
UP
2
