ES 50 – ES 80
25
Motor
OPEN
V2.1 X1/20 Motor OPEN
Motor
CLOSE
V2.2 X1/22 Motor CLOSE
Red traffic
light
V2.3 X1/13t
The red traffic light is on when the barrier is closed. The red
traffic light is also on during the time ‘warning prior to
opening’ (max. 230V/120W).
Amber or
flashing
light
V2.4 X1/14t
The contact for the Amber or the flashing light is closed when
the barrier is moving and during the time ‘warning prior
movement’ (max. 230V/120W).
Green
traffic light
V2.5 X1/15t
The green traffic light is on when the barrier is open. During
the time ‘warning before closing’ the green traffic light is out
(max. 230V/120W).
L1 V2.6 X1/14b N*
L1 V2.7 X1/17b L1, power supply 230V 50Hz
N V2.8 X1/19b N, power supply 230V 50Hz
Table 11
9.3 Visual indication
LED Colour Function
BT green
LED is lit when contact BT is closed or the receiver of the radio remote
control receives a signal.
BTA green LED is lit when contact BTA1 or BTA2 is closed.
BTZ1 green LED is lit when contact BTZ1A or BTZ1B is closed.
BTZ2 green LED is lit when contact BTZ2 is closed.
BTS1 green LED is lit when contact BTS1 is closed.
BTS2 green LED is lit when contact BTS2 is closed.
LS green LED is lit when the photo-cell is activated.
SEA green LED is lit when contact SEA is closed.
SEZ green LED is lit when contact SEZ is closed.
Vp yellow LED is lit when the main power is on.
Diag red Error code and display for radio remote control.
Table 12
9.4 Operating mode controller
Switch off the mains supply before altering the operating mode dip switches 1 - 9!
9.4.1 Pre-warning before opening (VWA)
The warning light (flashing or amber light) illuminates right after a signal to open, if pre-warning time
before opening is activated. The barrier opens after the pre-warning time has elapsed.
S1 off and S2 off: No pre-warning time
S1 off and S2 on: 1.5s pre-warning time before opening
S1 on and S2 off: 4.0s pre-warning time before opening
9.4.2 Pre-warning before closing (VWZ)
The warning light (flashing or amber light) goes on right after a signal to close, if pre-warning time
before closing is activated. The barrier closes after the pre-warning time has elapsed.
S3 off: No pre-warning time before closing
S3 on: 4.0s pre-warning time before closing
