Elka T 3000 User Manual

T 3000 - T 350
0
4
2
Pos. Qty. Part name
1 1 Hood
2 2 Pillow block
3 2 Plain bearing, main shaft
4 1 Main plate
5 1 Drive lever M
6 1 Drive lever F
7 1 Tension lever - holder T1
8 1 Tension lever - holder T2
9 2 Plain bearing, spring holder
10 1 Distance ring
11 1 Main shaft
12 2 Connecting lever
13 1 Gearbox shaft
14 2 Cylinder bolt, mechanics
15 4 Plain bearing, mechanics
16 1 Bearing plate
17 1 BLDC-Motor / planetary gear
18 1 Eccentric tappet, releasing device
19 1 Spring, releasing device
20 1 Plain bearing, eccentric tappet (releasing device)
21 1 Plain bearing, gearbox
22 2 Guide bar
23 2 Spring plate
24 2 Spring guide
25 2 Spring holder
26 1 Pressure spring (F1.1)
27 2 Support plate P
28 1 Pull plate P
29 1 Plain bearing, flange bearing
30 1 Joint head 12R
31 1 Tension lever
32 1 Housing
33 1 Base plate
34 1 Controller MO 24, board
35 1 Mounting plate
36 1 Top had rail with on-off switch and terminals
37 1 Controller MO 24, housing
