Elka T 3000 - Page 44

T 3000 - T 350
0
4
3
Pos. Qty. Part name
38 1 Power-supply unit
39 1 Bracket, mounting plate
40 1 Access panel
41 1 Lock cylinder with nut and lock bolt
42 1 Boom holder
43 1 Boom
44 1 Supporting plate for seal or sealing cap
45 1 Sealing cap, housing
46 1 Felt seal
47 2 Boom end cap
48 1 Bracket, spring assembly
49 1 Hood sheet, housing, right
50 1 Hood sheet, housing, left
51 2 Hood sheet, lever
Table 12
