Elkay LRAD - Drain Opening Locations; Hole Drilling Configurations; Mounting Systems

Off-Centered Right
Off-Centered Left
Centered
5"
5"
5"
5"
†
5"
Off-Centered Rear
DRAIN OPENING LOCATIONS
†
4-1/2" for LRAD(Q)1522
HOLE DRILLING CONFIGURATIONS
4"
4"
4" 4"
4" 4" 4"
4" 4" 4"
4" 4" 4" 4"
1
2
MR2
3
4
OS4
5
Elkay
2222 Camden Court
Oak Brook, IL 60523
www.elkayusa.com
Printed in U.S.A.
©2005 Elkay
1-135F (Rev. 5/05)
Lustertone
®
Single Bowl Sink
Models LRAD and LRADQ Series – A.D.A. Compliant
®
SPECIFICATIONS
Quick-Clip
®
Mounting System
U-Channel Type Mounting System
