Connect the bottle ller electrical harness
Fig. 6
Fig. 7
BOTTLE FILLING UNIT
Fig. 8
MOUNTING BOLT HOLES (6)
35
34
WALL MOUNTING PLATE
36
Page 8
ENLZSTL8WS_1G
1000004543 (Rev. A - 10/18)
