30 Installazione-Uso / Installation-User manual FL-FLR100
TECHNICAL CHARACTERISTICS
Power supply voltage 10,8 ÷ 26.8 Vdc
Consumption in idle @24 Vdc (Tx, Rx, Tx/Rx) 55 mA, 45 mA, 55 mA
Consumption in idle @12 Vdc (Tx, Rx, Tx/Rx) 45 mA, 35 mA, 45 mA
Consumption in alarm @24 Vdc (Rx, Tx/Rx) 50 mA, 60 mA
Consumption in alarm @12 Vdc (Rx, Tx/Rx) 40 mA, 50 mA
Consumption in fault @24 Vdc (Rx, Tx/Rx) 35 mA, 45 mA
Consumption in fault @12 Vdc (Rx, Tx/Rx) 30 mA, 40 mA
Pre-alarm obscuration thresholds 20%, 25%, 30%, 35%
Alarm obscuration threshold 35%
Minimum operating distance 5 meters
Maximum operating distance
150 meters (separate Tx and Rx)
100 meters (Tx/Rx and passive reflector)
Wavelength of the transmitter beam 890nm
Tolerance to the beam misalignment (separate
Tx and Rx)
±1°
Tolerance to the beam misalignment (TxRx unit
and passive reflector)
±0,5°; ±5°
Pre-alarm relay
1 A, 30 Vdc resistive load - NO/NC contact,
selectable via jumper
Alarm relay
1 A, 30 Vdc resistive load - NO/NC contact,
selectable via jumper
Fault relay
1 A, 30 Vdc resistive load - NO/NC contact,
selectable via jumper
Conventional detection circuit – input voltage
range
10 ÷ 20 Vdc
Conventional detection circuit – consumption in
pre-alarm condition
20 mA @20 Vdc
Conventional detection circuit – consumption in
alarm condition
40 mA @20 Vdc
Conventional detection circuit – reset pulse
duration
200 mS
Operating temperature (-10 ± 3)°C ÷ (55 ± 2)°C
Relative humidity (93 ± 3)%
Protection grade IP55
Passive reflector dimensions
10 cm x 10 cm
20 cm x 20 cm
30 cm x 20 cm
Dimensions 248x122x120 mm
Weight 900 g
Compliant with the standard: EN54-12: 2002
Line smoke detector using an optical light beam
Fire security
FLR100
Urmet S.p.A. 1293-CPR-0407
DoP n. 1293-CPR-0407
FL100
Urmet S.p.A. 1293-CPR-0406
DoP n. 1293-CPR-0406
For further information, please contact the manufacturer.
