18 Installazione-Uso / Installation-User manual FL-FLR100
CE LABELING AND RELEVANT DOCUMENTATION
According to the requirements of the EN54-12 Standard, below we report the CE labelling along with the
required information.
1293
is a trademark of URMET S.p.A.
Via Bologna, 188/C - 10154 Torino - Italy
14
1293-CPR-0406
DoP n. 1293-CPR-0406
FL100
EN 54-12
Line detector using an optical light beam
Fire safety
Documentation: see doc. LBT80777
14
1293
is a trademark of URMET S.p.A.
Via Bologna, 188/C - 10154 Torino - Italy
14
1293-CPR-0407
DoP n. 1293-CPR-0407
FLR100
EN 54-12
Line detector using an optical light beam
Fire safety
Documentation: see doc. LBT80777
14
INSTALLATION
The optical beam smoke detectors FLR100 and FL100 imply two different types of installation:
FLR100 – Transmitter/receiver unit (Tx/Rx) + passive reflector
This configuration involves a single FLR100, which operates simultaneously as transmitter and receiver
(Tx/Rx), and a passive reflector placed at a distance from the Tx/Rx unit between 5 and 100 meters.
The passive reflector must be chosen according to the distance from the FLR100 device:
Distance Type of passive reflector
5 – 20 meters 10cm x 10cm
20 – 50 meters 20cm x 20cm
50 – 100 meters 30cm x 20cm
FL100 – Separate transmitter unit (Tx) + receiver unit (Rx)
This configuration involves two separate FL100 devices. One of them is configured as transmitter (Tx) and
the other one as receiver (Rx).
In this case, the transmitter (Tx) and the receiver (Rx) can be placed at a distance between 5 and 150
meters.
