ElliptiGO 8S - 9 Control Cables

Owner’s Manual
1 FRAME
2 FOLDING STEERING COLUMN
3 STEERING EXTENDER
4 STEM
5 SHIFTER
6 GRIP
7 HANDLEBAR
8 BRAKE LEVERS
9 CONTROL CABLES
10 FRONT BRAKES
11 FORK
12 FRONT WHEEL
13 TIRE
14 FRONT QUICK RELEASE
15 KICKSTAND
16 REAR BRAKE
17 REAR WHEEL
18 INTERNALLY GEARED HUB
19 CHAIN
20 CRANK ARM
21 CHAINRING GUARD
22 CHAINRING
23 DRIVE ARM AXLE
24 DRIVE ARM
1
24
23
20
22
21
19
17
12
13
14
11
10
2
3
5
4
6
7
8
9
18
16
The picture below gives an overview of the components which make up the
ElliptiGO® 8S and 11R models. These names will be referred to throughout the
owner’s manual.
Terminology & Component Overview
8S and 11R Models
15
