Owner’s Manual
IV
Torque Requirements for Screws and Fasteners on 3C, 8C, 8S and 11R Models
Item Fastener Location / Description Fastener Size Tool Required Qty Torque (N-m)
1 Ergon GC3 Integral bar-end Grips to Handlebars (On Certain Models Only) M6x1.0 5mm allen 2 8
2 Gear Shifter to Handlebars M6x1.0 5mm allen 1 5-7
3 Brake Levers to Handlebars M5x0.8 4mm allen 2 4-5
4 Stem to Handlebars M5x0.8 4mm allen 4 4-5
5 Steeering Extender Star Nut M6x1.0 5mm allen 1 6-8
6 Stem to Steering Extender M6x1.0 5mm allen 2 8-10
7 Steering Column Base to Fork Steering Tube M6x1.0 5mm allen 2 6-8
8 Track Inserts to Frame - TIGHTEN VERY LIGHTLY TO AVOID STRIPPING! M3x.5 2.5mm allen 8 0.8-1.0
9 Kickstand to Frame M6x1.0 5mm allen 2 6-8
10 Rear Brakes to Frame M6x1.0 5mm allen 2 5-7
11 Front Brakes to Fork M6x1.0 5mm allen 2 5-7
12 Brake Pads to Brake Arms M6x1.0 5mm allen 4 6-8
13 Brake Cable to Brake Arms (Cable Anchor Bolt) M6x1.0 5mm allen 2 6-8
14 Bottom Bracket to Frame 1.37”-24 BB Tool 2 50-70
15 RH & LH Crank to Bottom Bracket M15x1 8mm allen 2 47-54
16 Chainring/Chain guard to RH Crank M8x0.75 6mm allen 5 8-10
17 Drive Arm Axle to RH Crank Arm 9/16”-20 RH 6mm allen 1 34
18 Drive Arm Axle to LH Crank Arm 9/16”-20 LH 6mm allen 1 34
19 Crank Axle Retention Screw to RH Crank Arm - TIGHTEN VERY LIGHTLY TO AVOID
STRIPPING HEX!
M6x1.0 LH 2.5mm allen 1 2
20 Crank Axle Retention Screw to LH Crank Arm - TIGHTEN VERY LIGHTLY TO AVOID
STRIPPING HEX!
M6x1.0 RH 2.5mm allen 1 2
21 Drive Arm Bearing Adjustment Screw to RH Axle (Under GO Cap) Set at Factory !! DO NOT TIGHTEN !!
22 Drive Arm Bearing Adjustment Screw to LH Axle (Under GO Cap) Set at Factory !! DO NOT TIGHTEN !!
23 Drive Arm Foot Basket to Drive Arm Body (Aluminum Drive Arms only) M6x1.0 4mm allen 16 8
24 Chain Tensioner to Dropout M4x.7 3 mm allen 4 2-3
25 Chain Tensioner Bolt M6x1.0 5mm allen 2 5-7
26 Shifter Cable Inner Cable Fixing Bolt - wrenches 1 3
27 Rear Wheel Axle Nuts to Frame 3/8” 15mm wrench 2 30
