Torque Requirements For Screws And Fasteners - Arc Model
Item Fastener Location / Description Fastener Size Tool Required Qty Torque (N-m)
1 Grips to Handlebars M4x0.70 3mm allen 2 2-3
2 Gear Shifter to Handlebars M6x1.0 5mm allen 1 5-7
3 Brake Levers to Handlebars M5x0.8 4mm allen 2 4-5
4 Stem to Handlebars M5x0.8 4mm allen 4 4-5
5 Steeering Extender Star Nut M6x1.0 5mm allen 1 6-8
6 Stem to Steering Extender M6x1.0 6mm allen 2 8-10
7 Steering Column Base to Fork Steering Tube M6x1.0 5mm allen 2 6-8
8 Kickstand to Frame M6x1.0 4mm allen 2 6-8
9 Rear Brakes to Frame M6x1.0 5mm allen 2 5-7
10 Front Brakes to Fork M6x1.0 5mm allen 2 5-7
11 Brake Pads to Brake Arms M6x1.0 5mm allen 4 6-8
12 Brake Cable to Brake Arms (Cable Anchor Bolt) M6x1.0 5mm allen 2 6-8
13 Swing Arm Axle to RH Frame Tube 9/16”-20 RH 15mm open end 1 34
14 Swing Arm Axle to LH Frame Tube 9/16”-20 LH 15mm open end 1 34
15 Swing Arm Axle Screw to RH Swing Arm Axle (Under GO Cap) M6x1.0 LH 4mm allen 1 6-8
16 Swing Arm Axle Screw to LH Swing Arm Axle (Under GO Cap) M6x1.0 RH 4mm allen 1 6-8
17 Swing Arm Clevis to Axle M6x1.0 4mm allen 2 6-8
18 Foot Platform Pivot Bracket to Drive Arm M6x1.0 4mm allen 8 4-5
19 Foot Platform Pivot Axle to Foot Platform Bracket M6x1.0 4mm allen 2 6-8
20 Foot Platform to Foot Platform Bracket M6x1.0 4mm allen 8 5-6
21 Bottom Bracket to Frame 1.375” -24 BB Tool 2 50-70
22 RH/LH Crank to Bottom Bracket M15x1 8mm allen 2 47-54
23 Chainring /Chain guard to RH Crank M8x0.75 5mm allen 5 8-10
24 Chain Keeper Bracket to Frame M6x1.0 4mm allen 1 6-8
25 Chain Keeper to Chain Keeper Bracket M5x.8.0 3mm allen 1 4-5
26 Drive Arm Axle to RH Crank Arm 9/16”-20 RH 6mm allen 1 34
27 Drive Arm Axle to LH Crank Arm 9/16”-20 LH 6mm allen 1 34
28 Crank Axle Screw to RH Drive Arm Axle (Under GO Cap) M6x1.0 LH 4mm allen 1 6-8
29 Crank Axle Screw to LH Drive Arm Axle (Under GO Cap) M6x1.0 RH 4mm allen 1 6-8
30 Cassette Lock Ring - Shimano Lock Ring Tool 1 30-50
31 Shifter Cable Inner Cable Fixing Bolt M6x1.0 5mm allen 1 6-8
32 Derailer Hanger to Frame M4x0.70 3mm allen 2 2-3
33 Derailer to Hanger M10x1.0 5mm allen 1 8-10
