ELMARK AN-100 - Main Technical Characteristics

Type
Model description
AN-Ø100
Motor
class II
15W
Ventilator model
Technical characteristics
AN-Ø120PS
AN-Ø120PSV
AN-Ø120VF
AN-Ø120
AN-Ø120V
AN-Ø120F
AN-Ø100PS
AN-Ø100PSV
AN-Ø100VF
AN-Ø100
AN-Ø100V
AN-Ø100F
AN-Ø120
Motor
class II
20W
MAIN TECHNICAL CHARACTERISTICS
The ventilator is connected to electric power network (electric current) of AC voltage of 230 V and 50 Hz frequency.
When it comes to electric shock protection, the ventilator belongs to Class II (230 V / 50 Hz).
Labelling of certain ventilator models and meanings of symbols are shown in the table below, while the schematic
overview, horisontal and mounting dimensions, as well as the construction characteristics are shown in tables 1 and 2.
O O
The ventilator is intended for exploitation in air temperatures in the range from +1 C to +40 C.
Noise level on 3m distance does not exceed 45 dB.
pull switch
pull switch+ flap
flap+flange
standard
flap
flange
pull switch
pull switch+ flap
flap+flange
standard
flap
flange
- Voltage: 230V
- Speed: 2500 rpm
- Power: 15W
3
- Air flow: 98 m /h
- Noise level: 41dB (À)
- Mass: 0,5kg
- Protection: IP-X4
- Voltage: 230V
- Speed: 2450 rpm
- Power: 20W
3
- Air flow: 190 m /h
- Noise level: 43dB (À)
- Mass: 0,65kg
- Protection: IP-X4
