16
4. Insert the thread between tension discs from the
right. Then pull both sides of the thread firmly to
insert it between tension discs.
5. Pass the thread through lower looper thread
guide (1).
4
Lower looper thread tension dial
5 Lower looper thread guide (1)
* Make sure that the thread is between the tension
discs.
(1) Thread
(2) Tension discs
6. Pass the thread through lower looper thread
guide (2).
7. Pass the thread through the looper thread
take-up lever (lower).
8. Pass the thread through lower looper thread
guide (3).
9. Pass the thread through lower looper thread
guide (4).
6
Lower looper thread guide (2)
7 Looper thread take-up lever (lower)
8 Lower looper thread guide (3)
9 Lower looper thread guide (4)
10. Turn the handwheel toward you until the
lower looper comes to the right, and pass the
threader through the hole on lower looper thread
guide (5).
Hook the end of the thread on the threader.
* Looper threader is optional.
* If you don’t have the looper threader, turn the
handwheel towards you until the lower looper
comes to its most left position.
Thread lower looper thread guide (5) from the
left side with a pair of tweezers. Then, turn the
handwheel towards you to move the lower looper
to the right position.
10
Lower looper thread guide (5)
(1) Lower looper thread
(2) Looper threader
4 5
6789
10
5
4
6
7
8
9
10
(1)
(2)
(1)
(2)
(2)
