ELNA 792D - Cleaning the Feed Dog

37
Cleaning the Feed Dog
1. Turn off the power switch and unplug the
machine.
2. Open the looper cover and side cover.
3. Remove the needles and presser foot.
4. Remove the needle plate set screw, and remove
the needle plate.
1
Needle plate
2 Needle plate set screw
5. Brush out the lint around the feed dogs to the
front by using the lint brush or use a vacuum
cleaner.
6. Reattach the needle plate, presser foot and
needles.
Close the looper cover and side cover.
1
Feed dog
1 2 3 4
5 6
2
1
1
