23
3. Insert the thread between tension discs from the
right. Then pull both sides of thread.
4. Turn the handwheel toward you to bring the
needle bar to its highest position, then pass the
thread through the thread take-up lever cover.
3
Left needIe thread tension dial
4 Thread take-up lever cover
5. Pass the thread through the needle thread guide
sliding the thread from right to left.
6. Pass it through the needle bar thread guide from
left to right.
7. Thread the left needle from front to back and pull
the thread about 10 cm (4˝) from the eye of the
needle to the back.
5
Needle thread guide
6 Needle bar thread guide
7 Left needle
– Gently pull all four thread ends towards the
back of the machine.
– Run threads under the presser foot and lower
the presser foot.
– Close side cover and looper cover.
– Turn handwheel toward you to chain off three
or four stitches.
The sewing preparation is now complete.
3 4
5 6 7
3
4
5
6
7
