89
Bridge Stitches
The following stitch patterns are bridge stitches, which are
used to insert straight stitches after a stitch pattern.
Example: Combination of pattern 053 and pattern 139 in
mode 2
z Select pattern 053 in mode 2.
Press the memory key.
q Memory key
x
Select pattern 139 in mode 2.
Press the memory key.
c
Two counts of the straight stitch are added to pattern
053.
w Bridge stitch
w
NOTE:
• The number e on the right of the stitch image
indicates stitch counts to be inserted.
• The stitch length and needle drop position of
following bridge stitches are independent from
those of the combined pattern.
r
MODE 2
z
x
c
The following bridge stitches will inherit the stitch
length and needle drop position of a previous pattern
in the programmed pattern combination.
MODE 2
Use patterns 135-138 with satin stitches.
r Pattern 137
Use pattern 140 if you want to add straight stretch
stitches.
MODE 2
e
q
q
