Touch On-Screen Display (OSD)
This monitor uses an easy-to-navigate Touch OSD interface. Use the settings menu in the
green sidebar to make adjustments to the monitor display settings.
Example of the Popup OSD Menu:
Refer to table below for OSD details.
Parameter
Available Adjustment
Video Source
Auto Scan
When enabled, the monitor will actively scan for new video port inputs.
Default: Enabled
Video Port
Discovery
When enabled, the monitor will automatically switch if a new video port is
connected.
Default: Enabled
Brightness
Adjust the brightness of the display.
Default: 100
Brightness
Sensor
The light sensor can be toggled on or off. When the light sensor is enabled,
the brightness cannot be changed manually.
Color Sensor
See section “ Intelligent Brightness Control and Color Sensor Functionality”
below.
Contrast
Adjust the contrast of the display.
Default: 50
Select the
desired
Video
Source
from here
Change
Brightness
by sliding
this green
bar.
Select the
desired
OSD
Setting
Menu from
here
