Elo Touch Solutions ET5502L - Page 13

User Manual: Interactive Digital Signage
SW602296 Rev D, Page 13 of 34
Sharpness
Adjusts sharpness of the displayed images.
Default: no sharpness adjustment
Sharpness function is disabled when the input source ratio is the same as the
panels native ratio
Black Level
The user can choose between Standard, 5%, 10% or 15% black level offset.
The saturation level of the colors change according to the chosen black level
offset.
Not available when the video source is from VGA.
Auto Adjust
Automatically adjusts the system clock to the input analog VGA video signal,
affecting the H-position, V-position, Clock, and Phase menu items.
Not applicable when using HDMI, DisplayPort video or the Computer
Module.
Dynamic Color
Modes
Preset color modes that change the color parameters to enhance color
definitions.
Available modes are: Standard, Movie, Gaming, Photo, Line mode, Legacy
HDMI
Default: Standard
Legacy HDMI is only available when the video input is the HDMI source.
Color
Temperature
Selects the displays color temperature. The available color temperatures are
9300K, 7500K, 6500K, 5500K, 3200K and User Defined.
Default: User Defined with R, G, and B all set to 100.
User Preset
If the User Preset option is selected, the user can change the color
temperature by changing individual R, G, and B gains on a scale from 0 to
100.
If the color space is YUV mode, then Hue and Saturation can be varied in this
menu.
Audio Select
Allows the user to choose the audio source. The choices are From Video
Source, Line in and ECM Line-in (available only if an ECM is detected)
If there is no Computer Module plugged in, and the video source is HDMI, the
options are: Line In and HDMI.
Default: Video Source.
Mute
Allows the user to enable or disable the sound on the touchmonitor.
Volume
Allows the user to change the volume level on the touchmonitor.
Recalling
Settings
Selecting “Recall Defaults” restores all factory default settings for
OSD-adjustable parameters (except OSD Language and OSD Position) and
for Preset Video Mode timings.
Serial Protocol
This menu allows the user to switch between the serial protocol and the
DDC/CI protocol.
DDC/CI protocol is used to communicate to a host computer via the video
signal.
Default: IIC
Tabletop
Enables or disables the Tabletop Thermal Protection Mode settings
Aspect Ratio
Allows the user to change the aspect ratio when not in the native resolution.
