OSD Timer
Adjusts how long a period of OSD button inactivity the touchmonitor will wait
before closing the OSD. The adjustable range is between 5 and 60 seconds.
Default: 15 seconds
OSD Language
Selects which language the OSD information is displayed in. The available
languages are: English, French, Italian, German, Spanish and Russian.
Default: English.
OSD Lock
When selected, the OSD will not popup when the Menu button is pressed.
If the OSD needs to be unlocked, press and hold the Menu button for five (5)
seconds. This will cause the monitor to unlock the OSD menu.
Power Lock
When enabled, the monitor will remain ON even if the power button is
pressed.
If this feature is enabled and power to the monitor is lost, when power is
regained, pressing the power button will turn on the monitor.
Monitor
Information
Displays the touchmonitor model and the monitor and touchscreen serial #
information
System
Temperature
Displays the real-time temperature of the Video Board
Note: CPU Sensor temperature is only available if the feature is supported by
the computer module.
Help & Support
Display information regarding Elo Touch Solutions contact information.
Power Behavior
When power to the monitor is lost and regained, the behavior that is chosen
will be executed.
Always On
Always Off
Last State
Default: Last State
RTC Settings
See section “Real Time Clock (RTC) Functionality” below for details
H-position
Moves the image horizontally on the display in single-pixel increments.
Default: centered.
Not applicable when using HDMI/DisplayPort video or the Computer Module.
V-position
Moves the image vertically on the display in single-pixel increments.
Default: centered.
Not applicable when using HDMI/DisplayPort video or the Computer Module.
Clock
Allows fine adjustments of the panels pixel dot clock.
Not applicable when using HDMI/DisplayPort video or the Computer Module.
Phase
Allows fine adjustments of the panels pixel dot clock phase.
Not applicable when using HDMI/DisplayPort video or the Computer Module.
GPIO
Allows user to select GPIO control between Easy Function and DDCCI.
See section “GPIO Direct Control” below for details.
