User Manual: Interactive Digital Signage
SW602296 Rev A, Page 17 of 39
All touchmonitor adjustments made through the OSD are automatically memorized as soon as
they are entered. This feature saves you from having to reset your choices every time the
touchmonitor is unplugged or powered off and on or if there is a power failure.
OSD Lock
When selected, the OSD will not popup when the Menu button is pressed.
If the OSD needs to be unlocked, press and hold the Menu button for five (5)
seconds. This will cause the monitor to unlock the OSD menu.
Power Lock
When enabled, the monitor will remain ON even if the power button is pressed.
If this feature is enabled and power to the monitor is lost, when power is regained,
pressing the power button will turn on the monitor.
Monitor
Information
Displays the touchmonitor model and the monitor and touchscreen serial #
information
System
Temperature
Displays the real-time temperature of the Video Board
Note: CPU Sensor temperature is only available if the feature is supported by the
computer module.
Help & Support
Display information regarding Elo Touch Solutions contact information.
Power Behavior
When power to the monitor is lost and regained, the behavior that is chosen will be
executed.
Always On
Always Off
Last State
Default: Last State
RTC Settings
See page 19 for details
H-position
Moves the image horizontally on the display in single-pixel increments.
Default: centered.
Not applicable when using HDMI/DisplayPort video or the Computer Module.
V-position
Moves the image vertically on the display in single-pixel increments.
Default: centered.
Not applicable when using HDMI/DisplayPort video or the Computer Module.
Clock
Allows fine adjustments of the panels pixel dot clock.
Not applicable when using HDMI/DisplayPort video or the Computer Module.
Phase
Allows fine adjustments of the panels pixel dot clock phase.
Not applicable when using HDMI/DisplayPort video or the Computer Module.
