Elpumps BP 10/4 User Manual

Проверил: Р.Ч./18.03.2015г.
3
2.) TECHNICAL INFORMATION
BP 10/4
BP 14/4
BP 18/3
BP 22/3
BP1/4
Voltage (V):
230
Frequency (Hz):
50
Maximum current drain (A):
6,5
4.8
5
6.1
Maximum power consumption
(W):
1400
1600
1000
1100
1300
Class of protection against
indirect contact:
I
IP X8
Protection *:
Condenser (F/V):
30/450
40/450
30/450
30/450
30/450
Insulation heat class:
B
130
Continuous
Vertical
Thermal protection:
Type of operation:
Position of operation:
Maximum delivery head (m):
60
80
60
75
55
Maximum liquid forwarding
(l/min):
85
85
60
60
50
Maximum height of the liquid
column loading the pump (m):
10
HO 7RNF 4x1mm
2
axial seal + spring gasket ring
Power cable:
Shaft seal:
Weight /kg/:
Dimensions of packing box:
17
19
19
20
12
* except for the two-pin plug and the connection box.
Liquid forwarding diagram
Height of lifting H(m)
3.) STRUCTURE, OPERATION
