- 36 -
- 37 -
10. Specification
ITEM DESCRIPTION
Video Format NTSC / PAL
Camera Input Channel 8 channel Composite BNC
Video Output Channel 1 channel Composite BNC
Recording Speed
NTSC:Max 60 fps (Total);
1fps~Max. 30 frames/s (Each Channel);
PAL:Max.50 fps (Total);
1fps~Max. 25 frames/s (Each Channel)
Recording Mode
Time schedule, Motion detection, Sensor activated, Motion detection &
Sensor activated
Resolution
Display
NTSC:704×480;
PAL:704×576;
Recording
NTSC:640×240(Half D1)
PAL:640×288(Half D1)
Compression Method
Enhanced MJPEG Recording(12-20K Bytes/frame);
MPEG 4-like Network Streaming;
Hard Disk Capacity
Over 1.0TBytes SATA Interface HDD×1
Estimated Record Length
120G Hard disk @ 50 fame per second @ Normal Quality
(120*1024*1024 K byte) ÷ (50*15*60*60) = 46 Hours
Recording Time 10days with 500GB HDD@ 25 fps for continuous recording mode.
LCD Display
15’’ color LCD, 1024*768, 450:1; View angle: 120
。
(H)100
。
(V)
Sensor, Alarm
4 Input (Normal Open / Normal Close)
1 Output (Alarm) (12 Pin DIP Switch)
PTZ(RS485 interface)
YES, 2 Pin for RS485 control Pan/Tilt/Zoom
Protocol:PELCO-D、PELCO-P
