16 User Manual THEIA HE-t String Inverters 357115.013, Issue 1.0, 2011 March
AC Fuses
AC fuses protect the supply conductors between the inverter and the utility grid.
They are not part of the scope of supply, and must be provided by the system installer.
Follow the local and national electrical regulations regarding rating of the AC fuses.
Table 3.3.2: AC current characteristics and fuse rating
Inverter Model Max AC Current Fuse Ratings Tripping Characteristics Type
THEIA 2.0 HE-t
THEIA 2.9 HE-t
THEIA 3.8 HE-t
THEIA 4.4 HE-t
10.5 A
15.2 A
19.7 A
23.0 A
15 A
20 A
25 A
30 A
B or C
Double
Pole
3.3.3. Surge Protection Devices
Overvoltage protection is used to prevent voltage surges through sensitive equipment. The
THEIA HE-t inverters are equipped with Temperature protected Metal Oxide Varistors
(TMOV) on both the DC and the AC side, which conduct excessive current from voltage
surges to ground.
PV systems mounted in an open or exposed environment need added protection on both the
DC and AC side, as they can act as lightning rods.
When the conductors are exposed to transients, their behavior limits the effectiveness of a
surge arrester. One or more surge arresters are needed in installations with long conductors
to obtain the required level of protection.
Always use qualified assesment when selecting the appropriate kA ratings for the
overvoltage protection device!
IEEE provides a good base for selecting kA ratings of the surge arrester: The THEIA HE-t
inverters are designed for category B: 100 kA – 150 kA per phase.
