Eltek Valere Theia He-t User Manual

User Manual THEIA HE-t String Inverters 357115.013 , Issue 1.0, 2011 April 23
Stringbox with DC Switch and no DC Fuse Holders
Figure 4.3.2: Customer connection area with
stringbox with DC switch
1. CAN terminal
2. Ethernet connection
3. Internal DC terminal blocks
4. DC ground terminal
5. Stringbox with no fuse holders and DC
switch
6. AC terminal block
No Stringbox: Connector Panel
Figure 4.3.3: Customer connection area with
connector panel
1. CAN terminal
2. Ethernet connection
3. Internal DC terminal blocks
4. DC ground terminal
5. Connector panel
6. AC terminal block
