2.3.1. Labels
The product label is attached to the lower right side of the inverter housing. It contains
important identification parameters and characteristics for the inverter, and must be clearly
visible after installation.
Figure 2.3.1: Product label
Table 2.3.1: Symbols appearing on the product label
Symbol Description Symbol Description
Discharge time 60 minutes:
High voltages are still present
inside the inverter for 1 hour
after switch OFF
Hot Surface: The heat sink
on the back of the inverter
can reach temperatures of up
to 90 ° C/194 ° F
Danger: High voltages are
present
Grounding: Ground terminal
CE Marking: The product
meets the EU safety, health and
environmental protection
requirements
Disposal: Do not dispose in
general waste! Collect the
various parts separately and
recycle them according to local
and national regulations
S – NO: Serial Number for
inverter identification
DC: Direct current terminal
AC: Alternating current
terminal
