8. Technical specifications ES51 / ES51US
The current approvals with their supplements can be found at:
http://service.eltex.de.
Supply voltage
Overvoltage category II
Power input
Output voltage
Loading capacity
Output current
Operating
ambient temperature
Storage temperature
Ambient humidity
Function and fault
signals (optional)
Mains power cable
Fuse (primary circuit)
Ground link
High voltage connec-
tions
Housing
Protection class
UL Approval (ES51US)
Dimensions
Weight
230 V AC 50/60 Hz; 115 V AC 60 Hz
according to IEC-standard 60664-1
exception: overvoltage category III
for version ES51/S
80 VA maximum
5 kV AC
ES51/K: 3.5 kV AC
depending on length of bar and length of high
voltage cable (see 3.5)
max. 6.2 mA at 5 kV
ES51: 0°C...+60°C (+32°F...+140°F)
ES51US: 0°C...+40°C (+32°F...+104°F)
-20°C...+80°C (-4°F...+176°F)
max. 80 % r.h., non-dewing
2 floating contacts, max. 250 V AC / 1 A or
24 V DC / 0.5 A loading capacity
green (high voltage active)
or red (fault) LED in front
approx. 2.5 meters with earthing-pin plug,
national version
see name plate
grounding terminal on housing
5x, plug-type
sheet metal steel with wall bracket
IP54, EN 60529
File No. E227156
230 x 140 x 82 mm (H x W x D), see Fig. 7
approx. 4 kg
as shown on
appliance
marking:
