eltherm ELTC/H-14 User Manual

2
CONTENT
INTRODUCTION
3
RECEIPT OF GOODS 3
SCOPE OF DELIVERY 3
STORAGE 3
DISPOSAL 3
FUNCTIONAL DESCRIPTION & TECHNICAL DATA
4
FUNCTIONAL DESCRIPTION 4
TECHNICAL DATA 4
Drilling pattern 4
Dimensions 5
CONNECTION PLAN 6
SPECIAL NOTES
7
Installation and safety information 7
OPERATION
8
OPERATING PANEL 8
Selecting and changing parameters 8
Protection against unauthorized operation 8
Error messages 8
PARAMETERS AND THEIR MEANING 9
Notes on commissioning 9
Declaration of Conformity 9
DOWNLOADS
10
RESERVATION
Subject to technical changes. Changes, errors and misprints do not constitute grounds for claims for damages.
For safety components and systems, the assembly instructions as well as the relevant and currently valid standards and regulations must be
observed.
eltherm GmbH
Ernst-Heinkel-Str. 6-10
57299 Burbach
T.: +49 2736 4413-0
F.: +49 2736 4413-50
info@eltherm.com
Document:
864305062000X
BU-097
Operation manual
ELTC-14 temperature controller up to
400°C with dierent socket types
Author: Peter Schmidt Date: 20.06.2013
Revision: 4 Julian Engel Date: 28.06.2023
For proper and safe use of the ELTC/H1-14, ELTC/H2-14 and
ELTC/H3-14 temperature controller, please follow these
instructions.
Please keep these instructions for future reference (e.g. in
the system documentation).

eltherm ELTC/H-14 Specifications

General

Brand	eltherm
Model	ELTC/H-14
Category	Temperature Controller
Language	English
