Eltorque QT Series User Manual

Ordering Information and Recommended Spare Parts
User Manual QT250 and QT800, ID 2021 2.0 July 2018
Page 63 of 86
Part No.
Description
Comment (text in BOM)
250.120.5R2
QT250 2.5 Dual CAN and Failsafe
Actuator
1
QT250 2.5 Dual CAN and
Failsafe
250.120.5R2H
QT250 2.5 Dual CAN and Failsafe
Actuator for Hybrid Marine Cable
2
QT250 2.5 Dual CAN and
Failsafe
800.120.5R2
QT800 2.5 Dual CAN and Failsafe
Actuator
1
QT800 2.5 Dual CAN and
Failsafe
800.120.5R2H
QT800 2.5 Dual CAN and Failsafe
Actuator Hybrid Marine Cable
2
QT800 2.5 Dual CAN and
Failsafe
900.001
Eltorque Configuration cable for QT-
series actuators
Config. Cable QT-series
1
with: 1blind cable gland, IP68, Non-EMC, RoHS
+ 4 standard Eltorque cable glands. Nickel plated brass, IP68, Non-EMC, RoHS.
Clamping range 8 – 14mm/0.32- 0.55 in.
2
with 3blind cable glands, IP68, Non-EMC, RoHS
+ 2 standard Eltorque cable glands. Nickel plated brass. IP68, Non-EMC, RoHS.
Clamping range 8 – 14mm/0.32- 0.55 in.
The Dual CAN actuator handles the CAN signal in a different way compared to
the standard CANopen actuator. The redundancy support is improved and makes
an actuator system more robust to errors. The Dual CAN actuator is otherwise
identical to the Gen 2.5 actuator.
