EN 33MAINTENANCE
4. check that the spring (7) of the engagement
cable is not too taut or too loose. Other-
wise, turn the adjusting nut (8) until the
spring reaches the right condition.
5. check the measurement of the spring (6)
again;
6. refit the collector channel (1), and always
put back the pin (2) and the split pin (3).
6.4 DISMANTLING AND REPLACEMENT
6.4.1 R
EPLACING WHEELS
1. Place the machine on a flat surface and
put blocks under a load-bearing part of
the frame on the side of the wheel to be
changed;
2. using a screwdriver, remove the snap ring
(1) and the washer (2);
3. pull out the wheel.
Smear some waterproof
grease on the axle and after refitting the
wheel, carefully refit the washer (2) and the snap ring (1).
Should you replace wheels or tyres, ensure that the right and
left wheels are of the same rolling diameter, and check that cutting deck is ad-
justed properly to prevent an uneven cut.
6.4.2 R
EPLACING AND REPAIRING TYRES
All puncture repairs or replacements will have to be carried out by a tyre repair
expert in accordance with the methods for the kind of tyre used.
NOTE
IMPORTANT
