27
5. Panic Bar:
The feed hopper entrance is designed with
a feed table that is equipped with a "Panic
Bar" which is designed to stop the feed
rollers should an operator be pulled into
the feed hopper.
Push the latch toward the roller to reset
the "Panic Bar". When the "Panic Bar" is
activated, the light on the front of the panel
will illuminate.
Fig. 6 PANIC BAR
Tripped
Normal Position
Trigger
Panel Light
