EMC Celerra NX4

11
For more information, refer to Celerra Tools on http://Powerlink.EMC.com
Blade types NX4 system
The NX4 blade enclosure contains 1 of the 2 blade types shown. Both blades in the
enclosure must be the same type as in the illustration.
4 port copper Ethernet
FRU label
10/100
2
3
FRU label
10/100
2
3
Blade 2
Blade 3
046-003-710_A01
FRU label
10/100
046-003-710_A01
FRU label
10/100
Blade 2
Blade 3
fxg 0 fxg 1
fxg 0
fxg 1
2 port 10 GbE optical Ethernet and 2 port copper
Or
CNS-001439
